Shimano XTR DI2 Rear Derailleur

Service Pages

Shimano Service Page

Manuals

XTR DI2 M9050 Series

Torque Values

Warning: Incorrect tightening of bicycle components can lead to damage, accident, injury, or even death. The accuracy of provided values is not guaranteed; always check directly with the manufacturer.
Bolt Name Tool Torque (Nm)
Pulleys 2.5 - 5
Plate axle 8.0 - 10
Stroke mounting bolt 0.5
Plate unit cover bolts 1.0 - 1.5
Mounting screw 8.0 - 10
Plate stopper pin 1
Left plate friction torque 3.5 - 5.4

Tools

T30 Torx Wrench

3 mm Hex Wrench

4 mm Hex Wrench

2 mm Hex Wrench

5 mm Hex wrench

#2 Phillips screwdriver
