Shimano Alivio Crankset

Service Pages

Shimano Service Page

Manuals

Crankset Crankset

Tools

#2 Phillips screwdriver

8 mm Hex Wrench

5 mm Hex Wrench

TL-FC16 Shimano Crank Assembly Tool

Torque Values

Warning: Incorrect tightening of bicycle components can lead to damage, accident, injury, or even death. The accuracy of provided values is not guaranteed; always check directly with the manufacturer.
Bolt Name Tool Torque (Nm)
Crank fixing screw (2 piece type) 12.0 - 14
Chainring fixing screws, largest / middle chainring 12.0 - 14
Chainring fixing screws, smallest chainring 16.0 - 17
Chain guard fixing screws 1.5 - 2
Crank mounting screw (octalink type) 35.0 - 50
Crank mounting screw (2 piece type) 0.7 - 1.5
